Amano EX-3500N
Electronic Time Clock
Engineered for value and simplicity, the EX-3500N Series is an electronic time recorder designed specifically for small businesses to easily and accurately log employee punch times.
Features:
- Easy, accurate, efficient
- Simple programming (set and forget) and operation
- Large, easy to read analog clock face
- Automatic Daylight Saving Time adjustment
- Perpetual calendar automatically adjusts for leap year
- Print format includes day/date, 0-23 hours, AM/PM, minutes (10th or 100th)
- Weekly, bi-weekly, semi-monthly and monthly pay periods
- Memory holding function (3 years)
- Surface detection function for correct printing position
- Automatic card feed, standard
- High-quality dot matrix printer for clean, clear printing
- Two color printing to show irregular time
- Built-in signal device
- Automatic IN/OUT positioning at the pre-programmed time
- Battery back-up retains memory
| Printing | Dot Matrix |
|---|---|
| Power Source | 110 / 120VAC or 220/240VAC ± 10%, 50/60Hz |
| Power Consumption | 5W Minimum, 30W Maximum |
| Ambient Temperature | 14°F to 104°F (-10°C to 40°C) |
| Relative Humidity | 10-90% (non-condensing) |
| Dimensions | 7-1/2”W x 8-3/4”H x 5”D (190mm x 224mm x 127mm) |
| Weight | 5.1 lbs (2.3 kg.) |
| Environment | Indoor use only, dust free, not in direct sunlight |
| Clock Accuracy | +3 seconds deviation per week |
| Time Card | 3.375” (86mm) wide, 0.244” spacing |
| Memory | Clock and programming data kept for 3 years without AC power |
